Formwork Coupler

Coupler for joining scaffold tubes and formwork props.

Factory Direct
CNC In-House
Batch QC Reports
OEM to Drawing
Formwork Coupler1 / 3
Other Accessories

Formwork Coupler

A steel coupler for joining scaffold tubes and formwork props. Available in slip and swivel types for bracing and support connections in formwork and falsework.

Specifications

  • Joins scaffold tubes and props
  • Pressed steel construction
  • Various tube diameters available
  • Slip or swivel type
Get a Quote WhatsApp Us

Prices are quoted based on product specifications, material/grade, quantity, destination and current market conditions. Contact us for the latest quotation.

Engineering-reviewed quote within 24 hours.

Technical Specifications

TypeSlip / swivel
MaterialQ235 steel
SurfaceGalvanized / painted
MaterialQ235 steel
Surface FinishGalvanized · Painted
Rated LoadInquire
Unit WeightInquire
PackagingBundled on pallet

Production Process

Cutting & forming01
Cutting & formingBar cutting, cold heading and plate forming to drawing dimensions.
CNC thread rolling02
CNC thread rollingRolled threads for fatigue strength and consistent pitch diameter.
Heat treatment03
Heat treatmentQuenching and tempering for class 8.8 and above, with process records.
Surface treatment04
Surface treatmentBlack oxide, zinc plating or hot-dip galvanizing to the specified thickness.
Gauge & batch test05
Gauge & batch testThread gauging, hardness and tensile checks with batch test reports.
Packing & marking06
Packing & markingSet or BOM packing, VCI protection and seaworthy crates.

Material Grades Explained

GradeNotes
Q235Plain carbon steel. Economic option for light and medium formwork loads. Not heat treated.
45#Medium carbon steel. The standard formwork tie rod grade in China; quenchable to class 8.8.
40CrAlloy steel. Higher hardenability and better fatigue performance than 45#; used where repeated reuse matters.
Class 10.9 boltQuenched and tempered alloy steel bolt used in the climbing cone set. Not electroplated without a documented baking cycle.
QT450-10Ductile (nodular) iron with 450 MPa tensile and 10% elongation. Used for sleeves and embedded plates where toughness and castability matter.
HRB400Hot-rolled ribbed bar (threaded steel) to Chinese standard. Used for embedded foot bolts; good bond with concrete.

Applications

Scaffold bracingFormwork supportFalsework

Procurement Guide

  • Specify tube diameter
  • Confirm slip or swivel type

Procurement Information

OEM / Custom
Own drawing or label welcome
MOQ
Trial orders OK · mixed SKU welcome
Lead time
Stock 3d · Custom 7-15d
Packaging
Seaworthy: pallet + strapping + waterproof
Payment
T/T · L/C at sight
Incoterms
FOB Tianjin · CIF · CFR · EXW
Real Application
Real Application

Backed by an ISO-certified factory

ISO 9001/14001/45001 · In-house CNC · 18+ years in formwork fasteners · 48+ export countries

Visit the factory

Related Products

Technical FAQ

Formwork Coupler — Answers for Engineers and Buyers

Formwork tie rods are commonly produced from medium and high carbon steel in 8.8 and 10.9 property classes. For corrosion protection: hot-dip galvanizing gives the thickest coating and suits outdoor and marine exposure; Dacromet (zinc-flake) coating avoids hydrogen embrittlement and is preferred for high-strength grades; electro-galvanized is an economical option for general use; black oiled bar is used indoors or where the rod is recovered and reused quickly.
