Embedded Tie Rod Assembly
Transfers one-side formwork load to embedded anchors in the cured structure.
Factory Direct
CNC In-House
Batch QC Reports
OEM to Drawing
1 / 3One-Side Formwork Accessories
Embedded Tie Rod Assembly
Embedded before pouring, the J-hook (dimensioned as diameter × length × hook width × hook length × thread) transfers formwork load into the cured concrete for single-sided concreting and foundation anchors. Supplied with positioning templates, anchor plates and full inspection documentation; hot-dip galvanized for long-term embedment.
Specifications
- J / L hook embedded anchors
- Diameter 12–36mm, custom length
- Positioning template included
- Anchor plate and nut options
- HDG finish for embedment
Prices are quoted based on product specifications, material/grade, quantity, destination and current market conditions. Contact us for the latest quotation.
Engineering-reviewed quote within 24 hours.
Technical Specifications
| Type | J / L hook or straight with plate |
| Diameter | 12–36mm |
| Embedment | Per project drawing; min. spacing/edge per design code |
| Template | Steel positioning template for bolt group |
| Finish | Hot-dip galvanized (45–85µm) or plain |
| Packaging | Kits with template, nuts and washers |
MaterialHRB400 hot-rolled ribbed bar (threaded steel)
Surface FinishPlain (black) · Zinc plated on request
Rated Load250 kN rated
Unit WeightD25 × 700 mm: 2.4 kg per piece
PackagingSet-packed with matched accessories · marked per set
Production Process
01
02
03
04
05
06Material Grades Explained
| Grade | Notes |
|---|---|
| Q235 | Plain carbon steel. Economic option for light and medium formwork loads. Not heat treated. |
| 45# | Medium carbon steel. The standard formwork tie rod grade in China; quenchable to class 8.8. |
| 40Cr | Alloy steel. Higher hardenability and better fatigue performance than 45#; used where repeated reuse matters. |
| Class 10.9 bolt | Quenched and tempered alloy steel bolt used in the climbing cone set. Not electroplated without a documented baking cycle. |
| QT450-10 | Ductile (nodular) iron with 450 MPa tensile and 10% elongation. Used for sleeves and embedded plates where toughness and castability matter. |
| HRB400 | Hot-rolled ribbed bar (threaded steel) to Chinese standard. Used for embedded foot bolts; good bond with concrete. |
Applications
Procurement Guide
- Send anchor layout drawing for bolt group template design
- Confirm embedment depth and edge distances with the engineer
- Request pull-out test data for project submittals
- For permanent embedment, require HDG or stainless
Procurement Information
- OEM / Custom
- Own drawing or label welcome
- MOQ
- Trial orders OK · mixed SKU welcome
- Lead time
- Stock 3d · Custom 7-15d
- Packaging
- Seaworthy: pallet + strapping + waterproof
- Payment
- T/T · L/C at sight
- Incoterms
- FOB Tianjin · CIF · CFR · EXW
Related Products
Technical FAQ
Embedded Tie Rod Assembly — Answers for Engineers and Buyers
A formwork tie rod is a high-strength threaded bar that, together with nuts, anchor plates and walers, holds formwork panels against the lateral pressure of fresh concrete. It passes through the wall section and is either fully recovered after stripping (through-tie used with a sleeve) or permanently embedded (lost-end / water-stop type).
