Wooden Beam Claw
Claw connector for H20 timber beams in wall and slab formwork.
Factory Direct
CNC In-House
Batch QC Reports
OEM to Drawing
1 / 3Climbing Cones & Sleeves
Wooden Beam Claw
Ductile iron (QT450-10) claw with spring-loaded toothed hook grips the 80mm H20 beam flange while the steel body ties the beam to the panel or waling. No tools required — hook, close and wedge-lock. Reusable, low panel damage and compatible with standard H20 timber beams and Hünnebeck-style wall formwork.
Specifications
- Fits H20 beam flange (80mm)
- QT450-10 ductile iron hook
- Spring-loaded toothed grip
- No-tool wedge lock
- Zinc plated, reusable
Engineering-reviewed quote within 24 hours.
Technical Specifications
| Beam Size | H20 timber beam, 80mm flange |
| Material | QT450-10 ductile iron hook + Q235 body |
| Action | Spring-loaded hook + wedge lock |
| Load Rating | System-dependent, up to ~12 kN per claw |
| Finish | Zinc plated |
| Packaging | Bulk in cartons |
Material45# steel (quenched and tempered)
Surface FinishPlain (black) · Zinc plated · Quenched (hardened) version available
Rated LoadGrip force depends on system; rated by beam type — see drawing
Unit WeightD15/10#: 0.55 kg per piece
PackagingCartons on pallet · marked per BOM
Production Process
01
02
03
04
05
06Material Grades Explained
| Grade | Notes |
|---|---|
| Q235 | Plain carbon steel. Economic option for light and medium formwork loads. Not heat treated. |
| 45# | Medium carbon steel. The standard formwork tie rod grade in China; quenchable to class 8.8. |
| 40Cr | Alloy steel. Higher hardenability and better fatigue performance than 45#; used where repeated reuse matters. |
| Class 10.9 bolt | Quenched and tempered alloy steel bolt used in the climbing cone set. Not electroplated without a documented baking cycle. |
| QT450-10 | Ductile (nodular) iron with 450 MPa tensile and 10% elongation. Used for sleeves and embedded plates where toughness and castability matter. |
| HRB400 | Hot-rolled ribbed bar (threaded steel) to Chinese standard. Used for embedded foot bolts; good bond with concrete. |
Applications
Procurement Guide
- Confirm beam flange width (80mm standard H20) before ordering
- Check panel hole spacing matches your claw layout
- Order spares for on-site loss — claws are lightweight
- For outdoor sites, request HDG or higher zinc class
Procurement Information
- OEM / Custom
- Own drawing or label welcome
- MOQ
- Trial orders OK · mixed SKU welcome
- Lead time
- Stock 7-30d · Custom 20-35d
- Packaging
- Seaworthy: pallet + strapping + waterproof
- Payment
- T/T · L/C at sight
- Incoterms
- FOB Tianjin · CIF · CFR · EXW
Related Technical Reading
Related Products
Technical FAQ
Wooden Beam Claw — Answers for Engineers and Buyers
A formwork tie rod is a high-strength threaded bar that, together with nuts, anchor plates and walers, holds formwork panels against the lateral pressure of fresh concrete. It passes through the wall section and is either fully recovered after stripping (through-tie used with a sleeve) or permanently embedded (lost-end / water-stop type).
